PPSU by BASF（Ultrason®）

Ultrason®P is BASF's brand designation for polyphenylsulfone (PPSU) , part of the Ultrason® family of high-performance thermoplastics . It is an amorphous material known for combining exceptional toughness with high heat resistance and excellent chemical resistance

Product Advantages

Superior impact strength: Charpy notched impact strength is nearly ten times higher than other high-temperature amorphous plastics

High heat resistance: Long-term service temperature up to 180°C (short-term up to 220°C)

Excellent hydrolysis resistance: Withstands repeated steam sterilization (134°C)

Inherent flame retardancy: Low smoke density and toxic gas emissions

Good chemical resistance: Resistant to detergents, oils, fats, and many chemicals

Transparent: Natural honey-colored tint, can be colored for various design options

Food contact approved: Compliant with FDA and EU regulations, with BPA/BPS-free options available for sensitive applications

Parameter Specifications

Trademark	Density (g/cm³)	MFR (g/10min)	HDT(℃)	Tensile Strength (MPa)	Volume Resistivity(Ω.cm)	Dielectric Strenth(KV/mm)	UL FlameRating
Ultrason®PPSU P 3010	1.29	35	198	74	1E+15	44	V0
Ultrason®PPSU S 2010	1.23	90	176	75	1E+13	40	HB
Ultrason®PPSU S 3010	1.23	40	177	75	1E+13	37	HB
Ultrason®PPSU S 6010	1.23	30	177	75	1E+13	37	HB
